Details
Details
- This extremely powerful vertical fogger produces explosive columns of smoke over 12m high.
- This is the ideal alternative to very expensive and difficult to use CO2 jet effects !
- The smoke column is illuminated by 2 independently controllable LED rings (35 RGB LEDs with 315Watt total power).
- The 3200W heater, together with the high-pressure compressor, provides very fast succession of powerful smoke bursts.
- Can also operate upside down to produce powerful downward smoke columns (2 optional “OMEGA BRACKET SMALL” needed).
- Controllable via 5 or 11 DMX channels.
- Prepared for wireless DMX : just plug in the optional WTR-DMX DONGLE.
- Optional omega brackets available for truss mounting.
- Works also in ECO mode: power consumption only 1600W.
- Recommended fog fluid: "Super fast dissipating" fog fluid.
- Connections: PowerCON TRUE1 + XLR 3pin + XLR 5pin.
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | 49 x 34 x 26 |
|---|---|
| General : Weight (kg) | 24 |
| General : Powerinput | AC 230V, 50Hz |
| General : Energy Label | No |
| General : Power consumption W | 3500 |
| General : Color | black |
| General : Display | LCD |
| General : Fixation | optional omega bracket |
| General : IP rating | indoor |
| Control : Modes | manual, DMX |
| Control : minimum DMX channels | 5 |
| Control : maximum DMX channels | 11 |
| Fx : liquid consumption | 7.5 ml / sec |
| Fx : liquid type | Smoke |
| Fx : tank capacity in L | 3.8 |
| Connections : input | 3 pin XLR, 5 pin XLR, wireless DMX optional, PowerCon® TRUE1 or compatible |
| Connections : output | 3 pin XLR, 5 pin XLR |
| Brand | BRITEQ |
| EANCode | 5420025647533 |
Manual & Downloads
Manual & Downloads
 BT-POWERJET Mk2 - Manual EN Size: (2.29 MB) |
BT-POWERJET Mk2 - Manual English |
| BT-POWERJET Mk2 - Manual FR Size: (2.14 MB) |
BT-POWERJET Mk2 - Manual Français |
| BT-POWERJET Mk2 - Manual NL Size: (2.13 MB) |
BT-POWERJET Mk2 - Manual Nederlands |
| BT-POWERJET Mk2 - Manual DE Size: (2.14 MB) |
BT-POWERJET Mk2 - Manual Deutsch |
| BT-POWERJET Mk2 - Manual ES Size: (2.14 MB) |
BT-POWERJET Mk2 - Manual Español |
| BT-POWERJET_MK2 PDF leaflet Deutsch Size: (1.03 MB) |
PDF_LEAFLET_BT-POWERJET_MK2_B04753_de.pdf |
| BT-POWERJET_MK2 PDF leaflet English Size: (1.03 MB) |
PDF_LEAFLET_BT-POWERJET_MK2_B04753_en.pdf |
| BT-POWERJET_MK2 PDF leaflet Français Size: (1.03 MB) |
PDF_LEAFLET_BT-POWERJET_MK2_B04753_fr.pdf |
| BT-POWERJET_MK2 PDF leaflet Nederlands Size: (1.03 MB) |
PDF_LEAFLET_BT-POWERJET_MK2_B04753_nl.pdf |
