- Powerful 70W LED white blinder with amber drift effect, behaves exactly like a halogen blinder!
- 12W RGB AURA-effects with full pixel control & 25 pre-programmed 2-layer effects.
- Rugged die-cast ALU-housing with waterproof IP65 rating!
- Extremely versatile mechanical mounting options:
- Use SPLICE connectors and your imagination to mechanically assemble multiple blinders into spectacular lines, circles, squares, ...
- Use CLAMP connectors to mount the blinder constructions directly into the truss.
- Use an optional omega bracket to mount the projector with hanging bracket in the truss.
- Preprogrammed amber drift effect and/or separate control for white & amber!
- Tunable CCT: from 1650K to 2700K
- 7 DMX-modes, both 8bit and 16bit: from 1 to 58ch
- Control channel with remote DMX-control for “red shift”, dimmer speed/curves, pixel order, …
- RDM-function for: channel mode, DMX-address, temperature monitoring, …
- OLED display with backlit touch buttons for easy configuration, even in the dark.
- No dedicated controller needed, fully self-contained operation with easy daisy chaining:
- PowerCON TRUE1 compatible in/out
- Waterproof 5pin XLR in/out
- Optional modification kit available to modify IP 5pin-XLR to 3pin-XLR
- Build-in 100V~240V 50/60Hz Power supply.
- The SPLICE and CLAMP connectors are optionally available!
NOTE: this product has IP65 rating while used for non-permanent outdoor installation and under normal conditions (not exposed to seawater).
Technical Specifications
Technical Specifications
| General : Dimensions (cm) | See drawings |
|---|---|
| General : Weight (kg) | 2 |
| General : Powerinput | AC 100 - 240V, 50/60Hz |
| General : Energy Label | No |
| General : Power consumption W | 75 |
| General : Color | black |
| General : Display | OLED |
| General : Fixation | optional omega bracket |
| General : IP rating | outdoor |
| Control : Modes | standalone fixed, manual, DMX |
| Control : Protocol | DMX, RDM |
| Control : programmable | No |
| Control : upgradable software | No |
| Control : minimum DMX channels | 1 |
| Control : maximum DMX channels | 58 |
| Light : lamp socket | No |
| Light : lamp | LED |
| Light : min. color temperature (K) | 1650 |
| Light : max. color temperature (K) | 2700 |
| Light : CRI | 70 |
| Light : colors | RGB |
| Light : mix colors | Yes |
| Light : max. refresh rate (kHz) | No |
| Connections : input | 5 pin XLR, PowerCon® TRUE1 or compatible |
| Connections : output | 5 pin XLR, PowerCon® TRUE1 or compatible |
| Brand | BRITEQ |
| EANCode | 5420025651936 |
Manual & Downloads
Manual & Downloads
 BTI-BLINDER1 FX - Manual EN Size: (2.66 MB) |
BTI-BLINDER1 FX - Manual V1.0 English |
| BTI-BLINDER1 FX - Manual FR Size: (2.69 MB) |
BTI-BLINDER1 FX - Manual V1.0 Français |
| BTI-BLINDER1 FX - Manual NL Size: (2.66 MB) |
BTI-BLINDER1 FX - Manual V1.0 Nederlands |
| BTI-BLINDER1 FX - Manual DE Size: (2.7 MB) |
BTI-BLINDER1 FX - Manual V1.0 Deutsch |
| BTI-BLINDER1 FX - Manual ES Size: (2.68 MB) |
BTI-BLINDER1 FX - Manual V1.0 Español |
| BTI-BLINDER1 FX - EC Declaration Size: (447.01 KB) |
BTI-BLINDER1 FX - EC Declaration of Conformity |
 BTI-BLINDER1 FX - IES Files Size: (5.02 KB) |
BTI-BLINDER1 FX - IES Files |
| BTI-BLINDER1 FX - Photometric Reports Size: (3.4 MB) |
BTI-BLINDER1 FX - Photometric Reports |
| BTI-BLINDER1_FX PDF leaflet Deutsch Size: (1.21 MB) |
PDF_LEAFLET_BTI-BLINDER1_FX_B05193_de.pdf |
| BTI-BLINDER1_FX PDF leaflet English Size: (1.21 MB) |
PDF_LEAFLET_BTI-BLINDER1_FX_B05193_en.pdf |
| BTI-BLINDER1_FX PDF leaflet Français Size: (1.21 MB) |
PDF_LEAFLET_BTI-BLINDER1_FX_B05193_fr.pdf |
| BTI-BLINDER1_FX PDF leaflet Nederlands Size: (1.21 MB) |
PDF_LEAFLET_BTI-BLINDER1_FX_B05193_nl.pdf |
Reviews & References
Customer Reviews (1)
- Mitigé Review by Simon Anthony
-
Produit qui fonctionne.Rating
L’effet aura n’apporte pas grand chose. Un cercle de led un peu plus gros (type led 0805 ou 1206) uniquement sur le tour extérieur aurait ete plus chouette. Cela fait plus gadgets, jouet, pas très visuel. Le blinder est intéressant. Le mode 22ch manque d’un dimmer juste pour le blinder, compliqué d’utiliser uniquement l’aura ou le blinder sans devoir forcément utiliser les 40 ou 58ch.
Une version moins cher avec uniquement le blinder serait mieux. Permettrait de faire un assemblage type portman retro mignature.
[Translation]
Product that works.
The aura effect doesn't add much. A slightly larger LED circle (LED type 0805 or 1206) only on the outer edge would have been nicer. It looks more like a gadget, a toy, not very visual. The blinder is interesting. The 22ch mode lacks a dimmer just for the blinder, complicated to use only the aura or the blinder without necessarily having to use the 40 or 58ch.
A cheaper version with only the blinder would be better. Would allow you to make a retro miniature portman type assembly.
[Answer]
If you just want to use the blinder and/or the aura effect there is also a 1 channel, 7 channel, 13 channel and a 18 channel mode. (Posted on 5/29/2025)
